Description
DYZ-4000 / DYZ-2000 / DYZ-1000 / DYZ-500 / DYZ-200 / DYZ-100
Characteristics
1=>Measurement of light scatter and decay of the insoluble particles suspended in water or transparent liquids.
2=>Automatic range switching, and multi point calibration.
3=>Equipped with average measurement function.
4=>Compliant with GLP Regulation and ISO 7027.
5=>Quantitative analysis of particle contents.
Specifications
|
Parameters/Model DYZ-4000 DYZ-2000 DYZ-1000 DYZ-500 DYZ-200 DYZ-100 |
||||||
|
Light source |
Tungsten halogen lamp (6V / 10W) |
|||||
|
Wavelength |
400nm-600nm |
|||||
|
Measuring mode |
NTU, FTU, EBC, ASBC |
|||||
|
Measuring range NTU |
0.000-50.00 50.01-200.0 200.1-2000 2000.1-4000 |
0.000-50.00 50.01-200 200.1-2000 |
0.000-50.00 50.01-200 200.1-1000 |
0.000-50.00 50.01-200.0 200.1-500 |
0.000-50.00 50.01-200.0 |
0.000-50.00 50.01-100.0 |
|
Minimum reading |
0.001 |
|||||
|
Allowable error of indication |
≤±6% |
|||||
|
Zero Drift |
≤±0.3%FS |
|||||
|
Stability of indication |
≤±1%FS |
|||||
|
Repeatability |
≤0.5% |
|||||
|
Sample bottle |
Φ 25 mm×95 mm |
|||||
|
Sample volume |
30–40 ml |
|||||
|
Calibration points |
7 |
6 |
5 |
4 |
3 |
3 |
|
Display |
LCD Touch Screen |
|||||
|
Interface |
USB，U disk |
|||||
|
Data storage |
1000 sets |
|||||
|
Power supply |
220V±22V，50Hz±1Hz，30w |
|||||
|
Overall dimensions |
430mm×430mm×300mm |
|||||
|
Weight (Gross) |
9kg |
|||||
